Stainless Steel 317L Pipes

Home > Stainless Steel > Stainless Steel 317L Pipes

Stainless Steel 317L PipesManufacturer, Supplier and Exporter in Bangkok, Thailand

Kamron Pipe and Tubes is a top manufacturer and supplier of high-quality stainless steel pipes located in Bangkok, Thailand. The company is known for its commitment to precise engineering, dependable supply chains, and customer satisfaction. Kamron offers a wide range of stainless steel products. Among these, Stainless Steel 317L Pipes are specifically made for excellent performance in highly corrosive situations. These pipes are built using modern technology and high-quality alloys to guarantee durability, strength, and resistance in extreme conditions. Kamron is a reliable partner for industries in need of long-lasting and efficient piping systems.

317L Stainless Steel Pipes Exporter in Thailand, SS UNS S31703 Pipes Exporter in Chiang Mai, 317L Stainless Steel Pipe Manufacturer in Pattaya, SUS 317L Pipes Price List in Thailand, ASTM A312 Stainless Steel 317L Pipe Supplier in Rayong, Stainless Steel 1.4438 Pipes in Nonthaburi

Stainless Steel 317L Pipes are low-carbon, molybdenum-bearing austenitic stainless steel. They mainly consist of Chromium (18–20%), Nickel (11–15%), Molybdenum (3–4%), and a maximum carbon content of 0.03%. This mixture provides great resistance to corrosion, especially against chlorides and other harsh chemicals. Mechanically, these pipes offer high tensile strength (approximately 75 ksi / 515 MPa), good yield strength (approximately 30 ksi / 205 MPa), and excellent ductility and weldability. The benefits of 317L include better resistance to pitting and crevice corrosion, improved resistance to stress corrosion cracking, and suitability for welding without the risk of carbide precipitation.

Stainless Steel 317L Pipes Specification

Specifications	ASTM A312, A358 / ASME SA312, SA358
Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24″ NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Thickness Range	0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type	Seamless / ERW / Welded / Fabricated / CDW
Form	Round Pipes, Square Pipes, Rectangular Pipes
Length	Single Random, Double Random & Required Length
End	Plain End, Beveled End, Treaded
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
EN 10216-5	EN 10216 317/317L Seamless Steel Pipe, EN 10216-5 1.4449 / 1.4438 Seamless Steel Pipes for pressure purposes
EN 10217-7	EN 10217 317/317L Welded Steel Pipe, Steel EN 10217-7 1.4449 / 1.4438 Welded Pipes for pressure purposes

Stainless Steel 317L Pipes Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
317L	min.	–	–	–	–	–	18.0	3.00	11.0	–
317L	max.	0.03	2.0	0.75	0.040	0.03	20.0	4.00	15.0	–

SS 317L Pipes Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
317L	515	205	35	95	217

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

SS 317L Schedule 40 Pipe Price List in Bangkok, Stainless Steel S31703 Pipes Supplier in Chiang Mai, SS 317L Pipes Supplier in Thailand, ASTM A312 Stainless Steel 317L Pipe Exporter in Pattaya, AISI 317L Pipes Supplier in Chonburi, 1 inch SS 317L Pipe Price in Nonthaburi, SS 317L Pipe Weight Chart, SS 317L Schedule 20 Pipe Thickness, 317L Austenitic Stainless Steel Pipe Supplier in Thailand

Why Choose Stainless Steel 317L Pipes from Kamron Pipes and Tubes?

Choosing Stainless Steel 317L Pipes from Kamron Pipes and Tubes offers corrosion resistance and excellent durability, ideal for harsh environments. Their pipes are precisely engineered for durability and reliability, conforming to stringent industry standards. Kamron offers solutions tailored to suit specific business requirements, backed by exceptional customer service. Furthermore, their commitment to quality ensures longevity and performance, making them a reliable choice for a variety of applications. Trust Kamron’s expertise in providing quality stainless steel for your needs.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 317L Pipes Supplier in Bangkok, Thailand

Kamron Pipes and Tubes, one of the largest suppliers of Stainless Steel 317L Pipes in Bangkok, Thailand, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 317L Pipes Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASME SA 312 TP317L Pipes Rayong, Stainless Steel 317L Pipes Supplier in Thailand, 317L Stainless Steel Pipes Exporter in Pattaya, SS UNS S31703 Pipes Supplier in Bangkok, SS 317L Schedule 20 Pipe Exporter in Nonthaburi

Types of Stainless Steel 317L Pipes

Are Custom Sizes Available for Stainless Steel 317L Pipes?

Yes, we offer custom sizes for Stainless Steel 317L Pipes to meet your specific requirements. Our team at Kamron Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@www.kamronpipes.com.

SS UNS S31703 Pipes Exporter in Nonthaburi, SUS 317L Pipes Supplier in Chiang Mai, 317L SS Pipes Manufacturer in Pattaya, 317L Austenitic Stainless Steel Pipe Dealer in Bangkok, Stainless Steel S31703 Pipes Manufacturer in Rayong, SS 317L Pipe Supplier in Thailand

Stainless Steel 317L Pipes are frequently used in chemical and petrochemical processing, pulp and paper production, food and beverage industries, and marine applications. They work particularly well in environments with high levels of chlorides, sulfides, or other aggressive substances. These pipes are also used in flue gas scrubbers, condensers, heat exchangers, and pharmaceutical equipment where hygiene and corrosion resistance matter. Thanks to their exceptional resistance and mechanical strength, 317L pipes function reliably in both high-temperature and corrosive conditions across various industrial sectors.
