Home > Stainless Steel > Stainless Steel 316H Welded Pipes
Kamron Pipe and Tubes, Bangkok, Thailand, is a reliable producer and supplier of industrial piping products with high performance. Some of their specialty products include Stainless Steel 316H welded pipes, which are meant for application in high-temperature and high-pressure applications. With increased carbon content compared to the normal 316, these pipes offer improved strength and creep resistance. Kamron provides its 316H welded pipes according to global quality standards and is apt for severe industries like power generation, petrochemicals, refineries, and heat processing plants where high durability and thermal stability are the need of the hour.
Stainless Steel 316H welded pipes contain chromium (16–18%), nickel (10–14%), molybdenum (2–3%), and with higher carbon content (up to 0.10%) for enhanced high-temperature strength. These pipes have superior mechanical properties, such as higher tensile and yield strength along with superior creep and stress rupture resistance. Superior corrosion resistance in acid and chloride media, better weldability, and long-term operation under higher temperature conditions are the main advantages, which make them perfect for thermal stress and corrosive media applications.
Specifications : ASTM A312 / ASME SA312
Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24″ NB available Ex-stock, OD Size available Ex-stock
Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Size : 1/2″ NB – 24″ NB
Type : Welded
Form: Round Pipes, Square Pipes, Rectangular Pipes.
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
| STANDARD | WERKSTOFF NR. | UNS |
| SS 316H | 1.4401 | S31609 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316H | Min | 0.04 | 0.04 | 0 | – | – | 16.0 | 2.00 | 10.0 | – |
| max | 0.10 | 0.10 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316H | 515 | 205 | 40% | 95 | 217 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 316H Welded Pipes guarantees excellent corrosion resistance, high strength, and durability. Designed for diverse industrial applications, it delivers reliable performance in tough environments while maintaining competitive pricing for cost-effective solutions.
Kamron Pipes and Tubes, a leading manufacturer and supplier of Stainless Steel 316H Welded Pipes in Bangkok, Thailand, offers a comprehensive range of high-quality pipes and tubing suitable for various industrial applications. Our extensive inventory and commitment to exceptional service make us a trusted choice for regional products.
| NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
| 1/8″ | ✓ | ✓ | ✓ | ✓ | |
| 1/4″ | ✓ | ✓ | ✓ | ✓ | |
| 3/8″ | ✓ | ✓ | ✓ | ✓ | |
| 1/2″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 3/4″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 1″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 1 1/4″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 1 1/2″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 2″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 2 1/2″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 3″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 4″ | ✓ | ✓ | ✓ | ✓ | ✓ |
| 5″ | ✓ | ✓ | ✓ | ✓ | |
| 6″ | ✓ | ✓ | ✓ | ✓ |
We offer custom sizes for Stainless Steel 316H Welded Pipes to meet your specific needs. Our dedicated team at Kamron Pipes and Tubes provides tailored solutions for all your piping and tubing requirements. For more information, contact us at sales@www.kamronpipes.com.
Stainless Steel 316H welded pipes are utilized in industries requiring strength, corrosion resistance, and reliability when operating at high temperatures. Their applications range from heat exchangers, pressure vessels, and boiler fittings to high-temperature chemical processing equipment. Power plants, refineries for oil and gas, and industrial furnaces utilizing constant thermal and mechanical stress also employ them. They are able to operate effectively under heat and pressure conditions, making them a choice for severe operating conditions and long-term durability in critical infrastructure and systems.
| Grade | Density (kg/m3) | Specific Heat 0-1000C (J/kg.K) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Electrical Resistivity (n.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 316H | 8000 | 500 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 740 |
