Kamron Pipe and Tubes, a well-respected manufacturer and supplier located in Bangkok, Thailand, has built a solid reputation for providing top-notch piping solutions to industries around the globe. Among their impressive lineup, Monel K500 Pipes stand out for their remarkable strength, resistance to corrosion, and durability even in the harshest conditions. Crafted with precision and in line with international standards, these pipes ensure outstanding performance in both marine and industrial settings. With a strong focus on quality, reliability, and customer satisfaction, Kamron Pipe and Tubes has become a trusted ally for all high-performance piping requirements across various applications.
Monel K500 Pipes are primarily made from nickel and copper, with added aluminum and titanium to boost their mechanical strength through a process called age-hardening. They offer excellent corrosion resistance, comparable to Monel 400, but with significantly enhanced tensile and yield strength. On a mechanical level, they provide impressive hardness, fatigue resistance, and toughness across a broad temperature range. Their benefits include a long service life, non-magnetic properties, and exceptional performance in both chemical and marine environments, making them a reliable choice for demanding industrial applications.
| Dimensions & Specifications | ASTM B 163 ASME SB 163 / ASTM B 165 ASME SB 165 |
|---|---|
| Sizes Available | 15 TO 150″ NB IN |
| Most famous types | Seamless / Welded / ERW / Fabricated |
| Manufacturing Pipes Forms | Round, Hydraulic & square pipes |
| Pipe End Bevel | Plain End, BBE, POE, BE, BOE, TBE, BLE, PBE, BOE, TOE, BSE, Beveled End, Treaded |
| DIN Werkstoff nr. | 2.4375 |
| UNS designation | N05500 |
| Monel K500 | S | Ni | Fe | C | Si | Al | Mn | Cu |
| 0.02 max | 63.0 min | 1.0 – 2.5 | 0.3 max | 0.5 max | 0.50 max | 2.0 max | 28.0 – 34.0 |
| Density | Yield Properties (0.2%Offset) | Melting Point | Elongational | Tensile Properties |
| 8.8 g/cm3 | Psi – 35,000 , MPa – 240 | 1350 °C (2460 °F) | 40 % | Psi – 80,000 , MPa – 550 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Monel K500 Pipes from Kamron Pipes and Tubes for their outstanding corrosion resistance, high strength, durability, and superior performance in extreme conditions. These characteristics make them ideal for demanding industrial applications.
Kamron Pipes and Tubes, one of the largest suppliers of Monel K500 Pipes in Bangkok, Thailand, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for monel products in the region.
| ASTM B165 Monel K500 Pipe OD mm | Pipe WT mm | in. | Sch | Kg/m |
|---|---|---|---|---|
| 13.72 | 1.65 | 1/4 | 10S | 0.50 |
| 13.72 | 2.24 | 1/4 | 40S | 0.64 |
| 13.72 | 3.02 | 1/4 | 80S | 0.81 |
| 17.15 | 1.65 | 3/8 | 10S | 0.64 |
| 17.15 | 2.31 | 3/8 | 40S | 0.86 |
| 17.15 | 3.20 | 3/8 | 80S | 1.12 |
| 21.34 | 2.11 | 1/2 | 10S | 1.02 |
| 21.34 | 2.77 | 1/2 | 40S | 1.29 |
| 21.34 | 3.73 | 1/2 | 80S | 1.65 |
| 26.67 | 2.11 | 3/4 | 10S | 1.30 |
| 26.67 | 2.87 | 3/4 | 40S | 1.71 |
| 26.67 | 3.91 | 3/4 | 80S | 2.23 |
| 33.40 | 2.77 | 1 | 10S | 2.13 |
| 33.40 | 3.38 | 1 | 40S | 2.54 |
| 33.40 | 4.55 | 1 | 80S | 3.29 |
| 33.40 | 6.352) | 1 | 160 | 4.30 |
| 42.16 | 2.77 | 1¼ | 10S | 2.73 |
| 42.16 | 3.56 | 1¼ | 40S | 3.44 |
| 42.16 | 4.85 | 1¼ | 80S | 4.53 |
| 42.16 | 6.352) | 1¼ | 160 | 5.69 |
| 48.26 | 2.77 | 1½ | 10S | 3.16 |
| 48.26 | 3.68 | 1½ | 40S | 4.11 |
| 48.26 | 5.08 | 1½ | 80S | 5.49 |
| 60.33 | 2.77 | 2 | 10S | 3.99 |
| 60.33 | 3.91 | 2 | 40S | 5.52 |
| 60.33 | 5.54 | 2 | 80S | 7.60 |
| 60.33 | 8.742) | 2 | 160 | 11.29 |
| 73.03 | 3.05 | 2½ | 10S | 5.35 |
| 73.03 | 5.16 | 2½ | 40S | 8.77 |
| 73.03 | 7.01 | 2½ | 80S | 11.59 |
| 88.90 | 3.05 | 3 | 10S | 6.56 |
| 88.90 | 5.49 | 3 | 40S | 11.47 |
| 88.90 | 7.62 | 3 | 80S | 15.51 |
| 88.90 | 11.132) | 3 | 160 | 21.67 |
| 101.60 | 3.05 | 3½ | 10S | 7.53 |
| 101.60 | 5.74 | 3½ | 40S | 13.78 |
| 101.60 | 8.08 | 3½ | 80S | 18.92 |
| 114.30 | 3.05 | 4 | 10S | 8.50 |
| 114.30 | 6.02 | 4 | 40S | 16.32 |
| 114.30 | 8.56 | 4 | 80S | 22.67 |
| 114.30 | 13.492) | 4 | 160 | 34.05 |
| 141.30 | 6.55 | 5 | 40S | 22.10 |
| 141.30 | 9.53 | 5 | 80S | 31.44 |
| 141.30 | 15.882) | 5 | 160 | 49.87 |
| 168.28 | 3.4 | 6 | 10S | 14.04 |
| 168.28 | 7.11 | 6 | 40S | 28.69 |
| 168.28 | 10.97 | 6 | 80S | 43.21 |
| 168.28 | 14.27 | 6 | 120 | 54.75 |
| 168.28 | 18.262) | 6 | 160 | 68.59 |
| 219.08 | 8.18 | 8 | 40S | 43.20 |
| 219.08 | 12.7 | 8 | 80S | 65.63 |
| 219.08 | 18.23 | 8 | 120 | 91.30 |
| 219.08 | 23.012) | 8 | 160 | 112.97 |
Yes, we offer custom sizes for Monel K500 Pipes to meet your specific requirements. Our team at Kamron Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@www.kamronpipes.com.
These Monel K500 Pipes find extensive use in industries that demand superior strength and corrosion resistance under extreme conditions. They’re commonly utilized in marine engineering, offshore oil and gas operations, and chemical processing sectors. Their ability to withstand seawater and sour-gas environments makes them perfect for applications like pump shafts, valves, and fasteners. In aerospace and power generation, they are employed in high-performance components that face stress and corrosive conditions. Monel K500 Pipes are highly valued for their durability, efficiency, and consistent performance in challenging industrial environments.
