Carbon Steel A671 GR CC 70 Pipes

Home > Carbon Steel > Carbon Steel A671 GR CC 70 Pipes

Carbon Steel A671 GR CC 70 Pipes Manufacturer, Supplier and Exporter in Bangkok, Thailand

Kamron Pipe and Tubes, a prominent manufacturer and supplier located in Bangkok, Thailand, has built a solid reputation for providing top-notch piping solutions that adhere to international standards. One of their standout products, the Carbon Steel A671 GR CC 70 Pipes, is designed for exceptional strength, durability, and dependable performance in tough industrial settings. These pipes find their way into various sectors, including oil and gas, power generation, chemical processing, and construction. With a focus on precision manufacturing, rigorous quality control, and prompt delivery, Kamron Pipe and Tubes guarantees that clients receive robust and long-lasting piping systems that can handle even the most challenging operating conditions.

Carbon Steel A671 GR CC70 Pipes Supplier in Bangkok, Carbon Steel A671 GR CC70 Pipes Exporter in Chiang Mai, ASTM A671 GR CC70 Pipes Sizes in mm, Carbon Steel A671 GR CC70 Pipes Manufacturer in Pattaya, Carbon Steel A671 GR CC70 Pipe Price List in Thailand, ASTM A671 GR CC70 Pipes Distributor in Rayong, Carbon Steel A671 GR CC70 Pipes in Nonthaburi, Carbon Steel A671 GR CC70 Pipes Supplier in Pattaya, Carbon Steel A671 GR CC70 Pipes Distributor in Thailand

The Carbon Steel A671 GR CC 70 Pipes are made from a blend of carbon, manganese, phosphorus, and sulfur, all carefully balanced to ensure excellent tensile strength, toughness, and resistance to wear and pressure. They boast impressive mechanical properties, such as high yield strength, impact resistance, and hardness, making them ideal for high-pressure and moderate-temperature applications. Additionally, these pipes are known for their good weldability and machinability, which allows for easy adaptation to various engineering and industrial needs. Their advantages include a long service life, consistent performance under stress, and cost-effectiveness, making them a go-to choice for critical industrial operations.

Carbon Steel A671 GR CC70 Pipes Specification

Specification	ASTM A671 /ASME SA671
Material Test Certificate	Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC
Type	EFW (ELECTRIC FUSION WELDED PIPES)
Material	A515 Gr 70
Outer Diameter Size	16″ NB To 100″ NB (Nominal Bore Size)
Wall Thickness	Schedule 20 To Schedule XXS (Heavier On Request) Up to 250 mm Thickness
Packaging	Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector
Class Designation	CLASS 10, 11, 12, 13, 20, 21, 22, 23, 30, 31, 32, 33, 40, 41, 42
Length	5 To 7 Meters, 09 To 13 Meters, Single Random Length, Double Random Length And Customize Size.
Other Testing	NACE MR0175, NACE TM0177, NACE TM0284, CHARPY V-NOTCH TEST, RADIOGRAPHIC EXAMINATION, XRAY, ULTRASONIC EXAMINATION, LIQUID PENETRANT, MAGNETIC PARTICLE, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc.
Dimension	All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM, ASME, API.
Value Added Services	Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment
Coating	Epoxy Coating / Colour Paint Coating / 3LPE Coating.
Shipment & Transportation	By Road – Truck / Train, By Sea – Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air – Freighter Civil Passenger and Cargo Planes
Standards	CC70, JIS JPI-SB49

Carbon Steel A671 GR CC70 Pipes Chemical Composition

A672 Grades	Chemical composition
A672 Grades	C	Si	Mn	P	S	Ti
CC70 / C70	0.27		~1.30

Carbon Steel A671 GR CC70 Pipes Mechanical Properties

A672 Grades	Yield Strength (N/mm2)	Tensile Properties (N/mm2)	Elongation (%)	Welding point tensile strength (N/mm2)
CC70 / C70	260	485~620	21	485~620

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASTM A671 GR CC70 Pipe Exporter in Thailand, Carbon Steel A671 GR CC70 Pipes Price List in Bangkok, Carbon Steel A671 GR CC70 Pipes Supplier in Chiang Mai, Carbon Steel A671 GR CC70 Pipes Exporter in Pattaya, Carbon Steel A671 GR CC70 Pipes Supplier in Chonburi, ASTM A671 GR CC70 Pipes Size Chart, Carbon Steel A671 GR CC70 Pipes Price in Nonthaburi, Carbon Steel A671 GR CC70 Pipe Weight Chart, ASTM A671 GR CC70 Pipes Thickness, Carbon Steel A671 GR CC70 Pipes Supplier in Thailand, Carbon Steel A671 GR CC70 Pipe Stockist in Chiang Mai

Why Choose Carbon Steel A671 GR CC70 Pipes from Kamron Pipes and Tubes?

Choosing Carbon Steel A671 GR CC70 Pipes from Kamron Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Carbon Steel A671 GR CC70 Pipes Size Chart

NB	Size	OD	40S	5S	10S	S10	S20	S40	S60	XS/80S	S80	S100	S120	S140	S160	XXS
NB	Size	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
	1/8”	10.29			1.2			1.73			2.41
	1/4”	13.72			1.7			2.24			3.02
	3/8”	17.15			1.7			2.31			3.2
15	1/2”	21.34	2.8	1.7	2.1			2.77		3.73	3.73				4.78	7.47
20	3/4”	26.67	2.9	1.7	2.1			2.87		3.91	3.91				5.56	7.82
25	1”	33.4	3.4	1.7	2.8			3.38		4.55	4.55				6.35	9.09
32	1 1/4”	42.16	3.6	1.7	2.8			3.56		4.85	4.85				6.35	9.7
40	1 1/2”	48.26	3.7	1.7	2.8			3.68		5.08	5.08				7.14	10.2
50	2”	60.33	3.9	1.7	2.8			3.91		5.54	5.54				9.74	11.1
65	2 1/2”	73.03	5.2	2.1	3.1			5.16		7.01	7.01				9.53	14
80	3”	88.9	5.5	2.1	3.1			5.49		7.62	7.62				11.1	15.2
90	3 1/2”	101.6	5.7	2.1	3.1			5.74		8.08	8.08
100	4”	114.3	6	2.1	3.1			6.02		8.56	8.56		11.1		13.5	17.1
125	5”	141.3	6.6	2.8	3.4			6.55		9.53	9.53		12.7		15.9	19.1
150	6”	168.3	7.1	2.8	3.4			7.11		10.97	11		14.3		18.3	22
200	8”	219.1	8.2	2.8	3.8		6.4	8.18	10.3	12.7	12.7	15.1	19.3	20.6	23	22.2
250	10”	273.1	9.3	3.4	4.2		6.4	9.27	12.7	12.7	15.1	19.3	21.4	25.4	28.6	25.4
300	12”	323.9	9.5	4	4.6		6.4	10.3	14.3	12.7	17.5	21.4	25.4	28.6	33.3	25.4
350	14”	355.6	9.5	4	4.8	6.4	7.9	11.1	15.1	12.7	19.1	23.8	27.8	31.8	35.7
400	16”	406.4	9.5	4.2	4.8	6.4	7.9	12.7	16.7	12.7	21.4	26.2	31	36.5	40.5
450	18”	457.2	9.5	4.2	4.8	6.4	7.9	14.3	19.1	12.7	23.8	29.4	34.9	39.7	45.2
500	20”	508	9.5	4.8	5.5	6.4	9.5	15.1	20.6	12.7	26.2	32.5	38.1	44.5	50
550	22”	558.8	9.5	4.8	5.5	6.4	9.5		22.2	12.7	28.6	34.9	41.3	47.6	54
600	24”	609.6	9.5	5.5	6.4	6.4	9.5	17.5	24.6	12.7	31	38.9	46	52.4	59.5
650	26”	660.4	9.5			7.9	13			12.7
700	28”	711.2	9.5			7.9	13			12.7
750	30”	762	9.5	6.4	7.9	7.9	13			12.7
800	32”	812.8	9.5			7.9	13	17.5		12.7
850	34”	863.6	9.5			7.9	13	17.5		12.7
900	36”	914.4	9.5			7.9	13	19.1		12.7

Carbon Steel A671 GR CC70 Pipes Material Equivalent

ASTM A671 Grade CC70 Pipe Types	Out diameter	Wall thickness	Length
ASTM A671 Grade CC70 SAW Pipe	16″ NB – 100″ NB	As per requirement	Custom
ASTM A671 Grade CC70 Seamless Pipe (Custom Sizes)	1/2″ NB – 60″ NB	SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160	Custom
ASTM A671 Grade CC70 ERW Pipe (Custom Sizes)	1/2″ NB – 24″ NB	As per requirement	Custom
ASTM A671 Grade CC70 Welded Pipe (in Stock + Custom Sizes)	1/2″ NB – 24″ NB	As per requirement	Custom

Largest Carbon Steel A671 GR CC70 Pipes Supplier in Bangkok, Thailand

Kamron Pipes and Tubes is one of the largest Carbon Steel A671 GR CC70 Pipes suppliers in Bangkok, Thailand, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.

Carbon Steel A671 GR CC70 Pipes Exporter in Thailand, Carbon Steel A671 GR CC70 Pipes Price List in Bangkok, ASTM A671 GR CC70 Pipes Supplier in Chiang Mai, Carbon Steel A671 GR CC70 Pipes Exporter in Pattaya, Carbon Steel A671 GR CC70 Pipes Supplier in Chonburi, Carbon Steel A671 GR CC70 Pipes Size Chart, Carbon Steel A671 GR CC70 Pipes Price in Nonthaburi, Carbon Steel A671 GR CC70 Pipes Weight Chart, Carbon Steel A671 GR CC70 Pipes Thickness, ASTM A671 GR CC70 Pipes Supplier in Thailand, Carbon Steel A671 GR CC70 Pipes Stockist in Chiang Mai

Types of Carbon Steel A671 GR CC70 Pipes

Are Custom Sizes Available for Carbon Steel A671 GR CC70 Pipes?

Yes, we offer custom sizes for Carbon Steel A671 GR CC70 Pipes to meet your specific requirements. Our team at Kamron Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@www.kamronpipes.com.

Carbon Steel A671 GR CC70 Pipes Supplier in Bangkok, ASTM A671 GR CC70 Pipes Exporter in Chiang Mai, CS A671 GR CC70 Pipes Manufacturer in Pattaya, Carbon Steel A671 GR CC70 Pipes Price List in Thailand, Carbon Steel A671 GR CC70 Pipes Distributor in Rayong, Carbon Steel A671 GR CC70 Pipes in Nonthaburi, ASTM A671 GR CC70 Pipes Supplier in Pattaya, Carbon Steel A671 GR CC70 Pipes Distributor in Thailand, Carbon Steel A671 GR CC70 Pipe Sizes in mm

These Carbon Steel A671 GR CC 70 Pipes are widely utilized in industries that demand reliable and durable piping solutions. They’re commonly found in oil and gas pipelines, power plants, chemical processing facilities, and water supply systems. Their capability to withstand pressure and moderate temperatures makes them perfect for boilers, heat exchangers, and industrial fluid transport systems. In the realms of construction and mechanical engineering, they serve as essential components for structural frameworks, heavy machinery, and industrial equipment. With their strength, versatility, and durability, these pipes are an excellent choice across a wide range of industrial and commercial applications.
